Understanding the Ethernet Gateway Lights and troubleshooting.
The process for setting up your Monnit Ethernet Gateway should be as simple as plugging in the Ethernet cable and power plug - three green LEDs means you're ready to go, But sometimes an LED may flash red, indicating a connection or settings issue. We have compiled this troubleshooting guide to help you determine what the problem could be. To help ensure that there are no issues to begin with, we recommend using the Ethernet Gateway configuration documentation located on Monnit's support page for information on properly setting up your Monnit Ethernet Gateway.
For any initial Ethernet Gateway issue:
Try unplugging the power to the gateway, wait 10 seconds, then plug it back in. If that doesn't work, please use a small tool, like a toothpick or paperclip, to press and hold the reset button on the back of the gateway. Press and hold the button for 5 seconds, until you see all three LEDs begin to flash red.
If the Ethernet Gateway 1st LED (on left) stays red or is flashing, possible causes are:
1. There is no internet access available.
2. Port 3000 is blocked.
3. DHCP is not enabled. If it is not enabled, you can configure the gateway to use a static IP address.
4. DNS cannot be resolved.
5. IP address is invalid.
6. The Ethernet cable is not connected.
a. The Ethernet cable is broken/damaged
b. The Ethernet jack is broken/damaged
7. There is an issue with the device MAC address.
View the Ethernet Gateway configuration documentation for more information on correctly setting the gateway parameters to address these issues.
If the Ethernet Gateway 2nd LED (middle) flashes red:
The gateway cannot connect to the server. The gateway configuration settings are not correct. Set the gateway back to the defaults by pressing and holding the reset button.
If the Ethernet Gateway 2nd LED (middle) stays red:
The Ethernet gateway has been able to contact the server and gets a response; however, the APN is not going from idle to active. There may be a problem with the hardware, contact Monnit support at firstname.lastname@example.org or 801-561-5555.
If you are still experiencing any issues that you are unable to troubleshoot with these tips, please contact Monnit support by emailing email@example.com or calling 801-561-5555.
